Description

Characters:

^l Laser oscillation in the CO2 optical wave, low dissipation, good stability and is not affected by external dust gas and mechanical looseness, the output of a laser beam is stable.

^l Processing speed is 2 to 3 times the traditional laser marking machine.

^l Wind cooling CO2 laser, no consumables, low maintenance, high photoelectric conversion rate,low consumption (800 w) or less, use cost.

^l Integrated design, small size (there are a whole cabinet and portable optional).

^l Environmental adaptation ability strong can be in vibration, shock, dust, humidity environment continuous work, easy to implement with optical CO2 coupling, which can realize remote work.

^l Bar code, QR code, graphics, text rules and irregular marking serial number, etc.

^l Software running on WINDOWS platform, Chinese/English interface, can be compatible with AUTOCAD,   CORELDRAW,   PHOTOSHOP software, such as PLT, PCW, DXF, BMP, etc, but also can be used directly SHX, ttf font.

Parameters:

Laser Power: 15W

Beam quality M2:  ＜2

Laser wavelength: 9.3um

Air cooling

Pulse frequency: 20 KHZ – 100 KHZ

Marking range:110 mm x 110 mm (can be customized) Marking Speed:0-7000mm/s

Marking Depth: ≤0.3mm

Marking Line Width: 0.01-0.2mm (based on difference material).

Min character Size: 0.015mm.

Repeat accuracy: + / – 0.003 mm

Marking area locating:Red-light locating system.

Power supply:AC 100-240 v 50/60 hz

Power: ≤800W

Environment: dust-free
